Nissan 300ZX Workshop Manuals

GENERAL SERVICING
When removing or installing various parts, place a cloth or padding onto the vehicle body to prevent scratches. Handle trim, molding, instruments, grille, etc carefully during removing or installation Be careful not to soil or damage them. Apply sealing compound where necessary while installing parts. When applying sealing compound, be careful that the sealing compound does not protrude from parts.

BODY END AND DOOR

• When removing and installing hood or back door, place a cloth or other padding on hood or back door
• corners to avoid scratching vehicle body
• When removing clip or fastener, refer to CLIP & FASTENER.
• Apply sealing compound where necessary when installing parts

Front End

1. Hood adjustment Adjust a t hinge portion
2. Hood lock adjustment After adjusting, check hood lock control operation Apply a coat of grease to
3. hood locks engaging mechanism
4. Hood opener Do not attempt to bend cable forcibly. Doing so increases effort required to unlock hood.
5. Bumper fascia. It is made of plastic, so do not use excessiveforce and take care to keep oil away from it
6. When adjusting or removing/installing hood or removing/installing hood switch, check theft warning system operation

WARNING:
a. Be careful not to scratch hood stay when installing hood. A scratched stay may cause gas leakage.
b. The contents of the hood stay are under pressure. Do not take apart, puncture, apply heat or allow fire near It.

Bumper shock absorber inspection

1. Check shock absorber for oil leakage, cracks or deformation
2. Function of shock absorber,
   1. Placevehicle in front of a wall
   2. Place a jack between bumper and wall, jack is positioned squarely with bumper directly in line with
   3. Apply pressureto compress shock absorber a t least 10.0 mm (0.394 in).
      • Use a jack with capacity of more than 600 kg (1,323 Ib).
3. Make sure bumper returnsto its original position when jack is retracted Replace if necessary

CAUTION: It I S not recommended to confirm proper installation by driving into walls or other barriers as this could cause personal injury or damage to the vehicle. When replacing shock absorbers, make sure they are of the same type and rating, and manufactured by the same maker.

Rear End

• Back door adjustment. Adjust a t hinge for proper back door fit
• Lock Adjust lock so that it is in the center of the striker. After adjusting, check back door lock operation
• Bumper fascia It is made of plastic, so do not use excessive force and take care to keep oil away from it.
• When adjusting or removing/installing back door or removing/installing back door lock system, check theft warning system operation.

A warm ambience of luxury and comfort permeates the snug yet spacious cabin of the 300ZX. It’s bright and airy (especially with the roof open), yet intimate. Everything is softly contoured, designed to please the eye as well as the mind. There’s plush carpeting, upholstery and roof trim. Power windows. Power locks. Power window locks. Power, heated mirrors. New leather touches include a leather-wrapped steering wheel and gear shift. This is only the beginning of a long list of posh standard features.

Have you been hugged today?
Over 1,000 different designs were tested before the 300ZX’s new driver and passenger power adjustable seats were perfected. They can be adjusted in 16 different ways. Thus providing the ultimate tailored fit for the largest or smallest of people. The driver’s seat is heated.

As you hug the road during tight turns, oversize side supports hug you, keeping you firmly in place. Your entire body is fully supported when you’re pushed back into the seat as you push the outer envelope of highperformance driving.

Nissan 300ZX DASHBOARD FEATURES:

• Tachometer
• Speedometer
• Rear defrost
• Cruise control
• Front/rear windshield wiper
• Voltmeter
• Engine temperature
• Fuel level
• Oil pressure
• Emergency lights
• Automatic climate control
• Turbo boost
• Sophisticated sound system
• Leather-wrapped steering wheel
• Side window defoggers
• Digital quartz clock
• Light controls

In the final analysis, the 300ZX’s chassis is a remarkable achievement. One that eliminates noise, vibration and harshness. And contributes to a level of handling that true sports car enthusiasts rarely can experience anywhere else.
