Land Rover Discovery Owner's and Service Repair Manuals

Land Rover Discovery Owner's, Service Workshop Manuals

The Land Rover Discovery is a series of mid-size luxury SUVs, produced by the British manufacturer Land Rover, which is part of Jaguar Land Rover. The Discovery has been in production since 1989 and has gone through multiple generations, each offering various updates and improvements in terms of technology, performance, and design.

The Discovery is renowned for its off-road capability, comfort, and versatility. It typically seats up to seven passengers across three rows and offers ample cargo space. Over the years, it has gained a reputation as a rugged yet refined SUV that can tackle challenging terrain while still providing a comfortable ride on paved roads.

Land Rover has incorporated advanced technology features into the Discovery, including various off-road driving aids, advanced infotainment systems, and safety features. Depending on the model year and trim level, it may come with features such as terrain response systems, air suspension, adaptive cruise control, lane-keeping assist, and more.

The Discovery competes in the luxury SUV segment, facing competition from vehicles like the BMW X5, Mercedes-Benz GLE, Audi Q7, and Volvo XC90. It caters to buyers looking for a premium SUV with both on-road comfort and off-road capability, making it a popular choice for those with adventurous lifestyles or families seeking a versatile and spacious vehicle.

THE NEW LAND ROVER DISCOVERY
Ever since the first Land Rover vehicle was conceived in 1947, we have built vehicles that challenge what is possible. These in turn have challenged their owners to explore new territories and conquer difficult terrains. Our vehicles epitomise our brand. Vehicles with exemplary design credentials and engineering capabilities. Which is how we continue to break new ground, defy conventions and encourage each other to go further. Land Rover truly enables you to make more of your world, to go above and beyond.

EXTERIOR
Design refinements give Discovery a lower, wider stance with an updated front grille and new bumpers. Land Rover Discovery R-Dynamic presents a compelling combination of sporting character and versatility, with unique bumpers, wheels and rear light designs. Roof options include fixed and sliding panoramic roofs and the Narvik Black contrast roof.

UNMISTAKABLE DESIGN
Newly sculpted headlights with a distinctive signature graphic and Matrix LED headlight technology* maximise visibility, while body-coloured side ingots add to the seamless design of the vehicle. The enhanced visual harmony of the rear end also elevates the vehicle’s contemporary appeal, with R-Dynamic featuring unique desaturated tail light designs.

CHOOSE YOUR COLOUR AND WHEELS
With twelve paint colours available, including a range of new colours such as Lantau Bronze, Hakuba Silver and Charente Grey, adding your personal touch to Land Rover Discovery is easy. And thanks to a wide variety of wheels, ranging from 20" to 22" in various finishes, your options for personalisation don’t end there. Use the configurator to build your perfect Land Rover Discovery.

INTERIOR
The redesigned, contemporary interior includes new second row seating, with deep seat cushions and ergonomic design providing enhanced comfort for you and your family. Touches such as the centre console’s deep storage compartment allow for greater convenience and flexibility, while the hidden-until-lit switches of the updated steering wheel and the intuitively designed toggle shift keep everything you need right at your fingertips.

STEP INTO YOUR WORLD
Premium materials are used extensively throughout Discovery’s luxurious cabin, including non-leather alternatives. Exclusive to R-Dynamic, Duo Tone seats with contrast stitching or piping* are also available in an Ebony/Light Oyster colourway. Now you can explore in enhanced style and comfort – no matter where your adventures take you.

UNCOMPROMISING SPACE AND PRACTICALITY
If you’re planning trips with up to seven of you, Discovery’s flexible seven-seat layout offers the perfect solution. Intelligent Seat Fold* allows you to easily configure the second and third row for an ample loadspace of up to 2,391 litres. Clever storage compartments throughout the interior allow you to carry items of all shapes and sizes with absolute ease.

SAFETY
With up to five ISOFIX points, installing child seats in this family SUV is easy. They ensure a strong connection between the child seat and the vehicle. Discovery achieved the maximum five-star safety rating from Euro NCAP and features a comprehensive system of up to eight driver and passenger airbags to help keep your family.

Land Rover Discovery includes a range of driver assistance features as standard, including 3D Surround Camera, Emergency Braking, Cruise Control and Speed Limiter, and Lane Keep Assist. Blind Spot Assist Pack and Driver Assist Pack are available to help with everyday driving and more tricky manoeuvres, delivering even greater safety and convenience.

POWERED CONVENIENCE
Discovery offers ultimate convenience. Powered gesture tailgate1 allows you to open and close the boot even when your hands are full, while the powered inner tailgate provides a platform for social events, or more everyday tasks like changing the kids’ muddy boots. Plus, the all-new Activity Key2 lets you enjoy your adventures without needing to take your conventional car key.

Land Rover Discovery Manuals PDF Listed:

• Land Rover Discovery 3 2009 Owner’s Manual
• Land Rover Discovery 4 Betriebsanleitung
• Land Rover Discovery 4 Instructieboekje
• Land Rover Discovery 4 Owner’s Handbook
• Land Rover Discovery Electrical Troubleshooting Manual
• Land Rover Discovery II 1998 fuse box diagrams
• Land Rover Discovery II Electrical Library
• Land Rover Discovery Parts & Accessory Catalog
• Land Rover Discovery R380 1996 Gearbox Overhaul Manual
• Land Rover Discovery Sport 2015 Betriebsanleitung
• Land Rover Discovery Sport 2015 fuse box diagram
• Land Rover Discovery Sport 2016 Betriebsanleitung
• Land Rover Discovery Sport 2016 fuse box diagram
• Land Rover Discovery Sport 2017 fuse box diagram
• Land Rover Discovery Sport 2018 fuse box diagram
• Land Rover Discovery Sport 2019 Owner’s Handbook
• Land Rover Discovery Workshop Repair Manuals + Wiring Diagrams
• Land Rover Discovery 1989 – 1998 fuse box diagrams
• Land Rover Discovery 1995 Body Repair Manual
• Land Rover Discovery 1995 Workshop Manual
• Land Rover Discovery 1999 Maintenance & Owner’s Manual
• Land Rover Discovery 2 2001 Owners Manual
• Land Rover Discovery 2004 – 2009 fuse box diagram
• Land Rover Discovery 2009 – 2016fuse box diagrams
• Land Rover Discovery 2017 fuse box diagram
• Land Rover Discovery 2018 fuse box diagram
• Land Rover Discovery 2021 Owner’s Handbook

COMFORT WITHOUT COMPROMISE
Create the perfect cabin environment for you, your family and friends. Unique to Land Rover Discovery, three rows of heated full-size seats1 mean each passenger can set their preferred level of warmth, while Four-zone Climate Control2 lets you configure the temperature in the first two rows and improve ventilation to the third. Optional Cabin Air Ionisation enhances driver and passenger wellbeing with a specially designed filter that captures fine particles from the outside air, such as PM2.5 and airborne allergens like dust and pollen. Entry and exit to the vehicle is made easier with Automatic Access Height, using air suspension to lower the vehicle by up to 40mm.

STAY CHARGED
Stay connected on all your adventures. Land Rover Discovery’s multiple USB-C charging points and additional USB port incorporated into the integrated Click and Go dock mean every occupant can enjoy fast charging and entertainment wherever they’re sat in the vehicle. Optional wireless device charging with phone signal booster also removes the need for wires or charging docks.

CAPABILITY
From refinement and fuel economy to effortless power, Discovery offers a range of engines. For clean, efficient power, our Mild Hybrid engines utilise a battery to harvest, store and redeploy energy normally lost during deceleration*. Our petrol engines provide an engaging, direct driving experience well suited to shorter journeys like shopping trips and after-school activities. Or, offering fantastic fuel economy over greater distance and producing higher levels of torque at
lower engine speeds, diesel engines are ideal for longer journeys, motorway cruising, towing and off-roading.

ULTIMATE ADAPTABILITY
All Wheel Drive (AWD) ensures a confident drive, on or off road. On slippery surfaces, such as grass and snow, AWD and Terrain Response work together to automatically balance torque between the front and rear wheels, maximising traction. Plus, a towing capability of up to 3,500kg and Advanced Tow Assist* make transporting anything from trailers to horseboxes easier.

EXPLORE IN CONFIDENCE
Achieve the best possible vehicle setup through Terrain Response 21, which automatically selects the optimum driving mode. Hill Descent Control takes the strain out of difficult slopes by maintaining a constant speed and applying braking separately to each wheel, while All Terrain Progress Control helps to set and maintain a steady speed in challenging off-road conditions. A 900mm wading depth and Wade Sensing technology also help to confidently tackle water crossings, alerting you if water approaches the maximum wading depth.

EFFORTLESS OFF ROAD
Making each journey easier, ClearSight Ground View1 allows you to effectively see ’through’ Land Rover Discovery’s bonnet and display multiple exterior views as you drive. Adaptive Dynamics automatically optimises the suspension settings to provide the perfect balance of refinement and agility, while Configurable Terrain Response allows you to individually personalise your off-road system preferences. Combine this with Discovery’s Twin-speed Transmission – which can prove invaluable in challenging conditions such as steep inclines or declines – and you’ll find that no adventure is out of reach.

IN-CAR TECHNOLOGY
Find what you’re looking for quickly – without getting lost in menus, screens and hidden features. Land Rover Discovery’s infotainment system, Pivi Pro, features an intuitive 11.4" Touchscreen interface for greater efficiency and enjoyment. Reach everyday tasks in two taps or less, right from the home screen. You’ll be accompanied by the latest in-car artificial intelligence, providing features such as the self-learning navigation system, for a fully connected journey*.

PREMIUM FUNCTIONALITY
With Pivi Pro you’ll enjoy fast start-up and even greater connectivity. With the Remote App*, your Discovery is always in the palm of your hand. Preset your navigation, confirm your vehicle’s location, check fuel levels and set the interior temperature – all before you’ve opened the car door. Along the way, intelligent re-routing can find you the best path to take, as well as updating parking availability, fuel price comparisons, café locations and traffic hotspots. Intelligent and intuitive, it also learns your regular and favourite routes, so that Smart Voice Guidance can make sure your song won’t be interrupted with unnecessary instructions. Featuring a 12.3" Interactive Driver’s Display, and an optional Head-up Display, which projects key information onto the windscreen in your line of sight, so you can focus on the road ahead.

ENTERTAINMENT FOR ALL
We know how important it is for you to stay connected. With Pivi Pro’s Online Pack with Data Plan1, you can enjoy your favourite music streamed from multiple services, including Spotify, TuneIn and Deezer, right through your Discovery’s speakers. As passengers, you can all take full advantage of the optional Wi-Fi Enabled with Data Plan, streaming entertainment with up to 20GB of data per month. Whether that’s browsing your socials, playing online games, or immersing yourselves in a movie.

SEAMLESS CONNECTIVITY
Your vehicle stays up to date through Software Updates. The vehicle’s infotainment, telematics and various control modules can all be updated remotely to help ensure optimal performance. It means that your vehicle just keeps getting better. Optional wireless device charging with phone signal booster lets you charge compatible smartphones without the need for wires or a charging dock. While in the car, your phone will use the vehicle’s antenna for improved signal and clearer calls.

YOUR DISCOVERY
Put freedom and adventure back on the map with Land Rover Discovery or Land Rover Discovery R-Dynamic. Discovery is made for the modern family, combining reductive design with a versatile interior, innovative technologies and enhanced capability to create something unmistakable. R-Dynamic takes these credentials and adds a bolder, stealthier stance – giving a strong sporting character.

LAND ROVER DISCOVERY COMMERCIAL
Land Rover Discovery Commercial combines an assertive, recognisable stance with a purposeful interior and privacy glass. The 2,024 litre loadspace is maximised through additional underfloor stowage and convenient side and tailgate access. Outstanding refinement and versatility elevate its class-leading practicality.

ACCESSORIES
Tailor your Land Rover Discovery to your specific needs with a range of accessories, allowing you to take everything you need on your adventures. The Luggage Roof Box, Versatile Roof Rack or the Ski/Snowboard Carrier are perfect for family trips, while towing accessories mean you can transport all your equipment with confidence. Plus, our range of Pet Packs are on hand to transport pets with comfort and convenience.

THE LAND ROVER COLLECTION
Our exclusive collection of accessories is inspired by our vehicles and made with a quintessentially British sense of style.

Land Rover Chronograph Watch – This timepiece features a solar charging face with date aperture and instrument cluster chronograph. Orange accent to the sub-dials, outer dial and second hand. Premium Golf Umbrella – Non-conductive fibreglass frame golf umbrella. Features vented canopy for additional wind resistance and Land Rover wordmark to the canopy edge.

Modern Driver’s Jacket – Be ready for every kind of road. This contemporary driver’s jacket offers incredible versatility. Features quilted shoulders, branded poppers to the cuffs and a brushed metal effect wordmark tag. Water-resistant zips and DWR® coating.

Land Rover Business Hard Case – Taking design cues from our Land Rover skid plate, this business case in Graphite Grey is ready for whatever the workday brings. A polycarbonate shell, an aluminium frame and TSA-approved locks mean important documents are always kept secure.

Weekender Bag – Packed with versatility. Made from highly supple oil-washed natural grained brown leather, this Weekender Bag is flexible in every sense. Ideal for day trips or extended excursions, it features sturdy handles, a detachable padded shoulder strap and a practical
zip pocket. Includes protective dust bag.

Defender Multi-tool – Black steel credit card sized multi-tool crafted into a Defender silhouette. Features a range of practical tools including tyre tread gauge.

THE WORLD OF LAND ROVER
Your Land Rover has been designed and engineered to help you make more of your world. It can take you to places others simply can’t reach, in a style that cannot be matched. With a vehicle from Special Vehicle Operations, that sense of individuality can be taken to even greater heights. As a celebration of the Land Rover lifestyle, we’ve put together a range of experiences, publications and the Land Rover Lifestyle Collection. There’s a world to explore. Get out there and enjoy it.
