MAN Trucks ECU EDC7 Engine Fault Codes List

MAN Trucks ECU EDC7 Engine Fault Codes List

Table of MAN ECU EDC7 Engine Fault Codes List

MAN ECU EDC7 Engine Fault Code
Code (SPN) Description
81 The difference between exhaust pressures.
94 fuel feed pressure.
98 Oil level.
100 Oil pressure.
102 Pressure supercharging charge air pipe after intercooler (intercooler).
105 Combustion air temperature before entering the cylinders (after AGR).
108 Atmosphere pressure.
110 The coolant temperature.
168 Voltage batteries.
171 Ambient temperature.
173 exhaust gas temperature before further purification.
175 The fuel temperature.
190 The engine speed.
609 1 CAN module.
651 Bank1, the injector 1 (four-cylinder engine cylinder №1; six engine cylinder №1; eight-cylinder engine main №1, №5 slave cylinder; ten-cylinder engine main №1, №6 slave cylinder; twelve-cylinder engine№1 main cylinder № 12slave).
652 Bank2 injector 1 (four-cylinder engine cylinder №3; six engine cylinder№5; №2 eight-cylinder engine cylinder head, the cylinder №7 slave;№5 ten-cylinder engine cylinder head, the cylinder №10 slave; twelve-cylinder engine №5 main cylinder №8 slave).
653 Bank1, injector 2 (four-cylinder engine cylinder №4; six engine cylinder №3; eight-cylinder engine main №3, №6 slave cylinder; №2 ten-cylinder engine cylinder head, the cylinder №7 slave; twelve-cylinder engine №3 main cylinder № 10 slave).
654 Bank2, injector 2 (four-cylinder engine cylinder №2; №6 cylinder six-cylinder engine, eight-cylinder engine main №4, №8 slave cylinder;№3 ten-cylinder engine cylinder head, the cylinder №8 slave; twelve-cylinder engine №6 main cylinder № 7 slave).
655 Bank1, an injector 3 (six engine cylinder №4; №4 ten-cylinder engine cylinder head, the cylinder №9 slave; twelve-cylinder engine №2 main cylinder №11 slave).
656 Bank2, an injector 3 (six engine cylinder №4; twelve cylinder engine cylinder №2
the maincylinder №11slave).
959 Time and date (incorrect value seconds).
960 Time and date (incorrect value minutes).
961 Time and date (incorrect value hours).
962 Time and date (incorrect value days).
963 Time and date (month incorrect value).
964 Timeand date (s wrong value).
1079 a pressure sensor supply line.
1080 fuel pressure sensor supply low pressure circuit, the boost pressure sensor, oil pressure sensor, and exhaust pressure sensor.
1131 The temperature of the charge air boost in the tube after the intermediate cooler (intercooler).
2039 FFR1 (driving motor unit or computer).
3004 Control deviation AGR.
3007 Invalid query DM4.
3009 Too high engine speed.
3014 Main relay (inside the control unit).
3016 FFR1: Invalid message due to engine brake.
3017 FFR1: Wrong message on a given moment.
3018 FFR1: Invalid message for limit controller.
3020 FFR1: Invalid message due EDR (the maximum speed limiter).
3022 FFR1: Setting ZDR (intermediate speed regulation).
3023 FFR1: Invalid request message "MEOS" (an instant increase in engine speed).
3024 FFR1: Invalid request message off of a linear function.
3025 FFR1: Checking the number of reserved memory.
3029 FFR2: Wrong message, the installation of idling.
3030 FFR2: Invalid message for limit controller.
3031 FFR2: Setting too high LLR.
3032 FFR2: Invalid request message idling.
3033 FFR2: Error messages start request.
3034 FFR2: Error message engine stop request.
3035 FFR2: Checking the number of reserved memory.
3038 FFR3: Error in the notice of the parking lot.
3039 FFR3: Checking the number of reserved memory.
3045 The starter.
3046 The atmospheric pressure sensor ..
3063 Inertia phase has not been completed.
3064 EDC standalone mode.
3069 Redundant control speed.
3076 Wrong Number (ID) FFR unit.
3077 No number (ID) FFR unit.
3081 Disable wastegate.
